PT-7528 Series Advanced Settings
4-14
clockAccuracy
Setting Description Factory Default
0x21
The clockAccuracy characterizes a clock for the purpose of the
best master clock (BMC) algor
ithm. This value is fixed at 0x21,
which means the time of the EDS switch is accurate to within
100 ns.
0x21
Timescale
Setting Description Factory Default
PTP or ARB • PTP timescale: In normal operation, the epoch is the PTP
epoch and the timescale is continuous. The time unit is SI
seconds, as realized on the rotating geoid (SI: International
System).
•
ARB timescale: In normal operation, the epoch is set by an
administrative procedure. The epoch can be reset during
normal operation. Between invocations of the
administrative procedure, the timescale is continuous.
Additional invocations of the administrative procedure may
introduce discontinuities in the overall timescale.
PTP
ARB Time
Setting Description Factory Default
0 to 255
The geoid of the PTP clock reference time (seconds).
0
Leap59
Setting Description Factory Default
True or False
The last minute of the current UTC day contains 59 seconds. If
the epoch is not PTP, the value will be set to FALSE.
False
Leap61
Setting Description Factory Default
True or False
The last minute of the current UTC day contains 61 seconds. If
the epoch is not PTP, the value will be set to FALSE.
False
UTC Offset Valid
Setting
Description
Factory Default
True or False The initialization value will be TRUE if the value of the current
UTC offset is known to be correct; otherwise, it will be FALSE.
False
UTC Offset
Setting Description Factory Default
0 to 255 The known UTC offset (seconds). 0
Status
Setting Description Factory Default
N/A Shows the current IEEE 1588 PTP status. N/A
PTP Port Settings
Shows the current switch PTP port settings.
