PT-7528 Series Advanced Settings

4-44

• Port 1 connects a single untagged device and assigns it to VLAN 5; it should be configured as Access Port

with PVID 5.

• Port 2 connects a LAN with two untagged devices belonging to VLAN 2. One tagged device with VID 3 and

one tagged device with VID 4. It should be configured as Trunk Port with PVID 2 for untagged device and

Fixed VLAN (Tagged) with 3 and 4 for tagged device. Since each port can only have one unique PVID, all

untagged devices on the same port must belong to the same VLAN.

• Port 3 connects with another switch. It should be configured as Trunk Port GVRP protocol will be used

through the Trunk Port.

• Port 4 connects a single untagged device and assigns it to VLAN 2; it should be configured as Access Port

with PVID 2.

• Port 5 connects a single untagged device and assigns it to VLAN 3; it should be configured as Access Port

with PVID 3.

• Port 6 connect a single untagged device and assigns it to VLAN 5; it should be configured as Access Port

with PVID 5.

• Port 7 connects a single untagged device and assigns it to VLAN 4; it should be configured as Access Port

with PVID 4.

After the application is properly configured:

• Packets from Device A will travel through Trunk Port 3 with tagged VID 5. Switch B will recognize its VLAN,

pass it to port 6, and then remove tags received successfully by Device G, and vice versa.

• Packets from Devices B and C will travel through Trunk Port 3 with tagged VID 2. Switch B recognizes its

VLAN, passes it to port 4, and then removes tags received successfully by Device F, and vice versa.

• Packets from Device D will travel through Trunk Port 3 with tagged VID 3. Switch B will recognize its VLAN,

pass to port 5, and then remove tags received successfully by Device H. Packets from Device H will travel

through Trunk Port 3 with PVID 3. Switch A will recognize its VLAN and pass it to port 2, but will not

remove tags received successfully by Device D.

• Packets from Device E will travel through Trunk Port 3 with tagged VID 4. Switch B will recognize its VLAN,

pass it to port 7, and then remove tags received successfully by Device I. Packets from Device I will travel

through Trunk Port 3 with tagged VID 4. Switch A will recognize its VLAN and pass it to port 2, but will not

remove tags received successfully by Device E.

Configuring Virtual LAN

VLAN Settings

To configure 802.1Q VLAN and port-based VLANs on the Moxa switch, use the VLAN Settings page to

configure the ports.

VLAN Mode

Setting Description Factory Default

802.1Q VLAN Set VLAN mode to 802.1Q VLAN 802.1Q VLAN

Port-based VLAN Set VLAN mode to Port-based VLAN

Unaware VLAN Set VLAN mode to Unaware VLAN

NOTE

Only

EDS-728 and IKS-6726/6728 provides the Unaware VLAN function.
