PT-7528 Series Advanced Settings

4-78

The table below shows the threshold of the temperature and power by different fiber types.

Using the MAC Address Table

This section explains the information provided by the Moxa switch’s MAC address table.

The MAC Address table can be configured to display the following Moxa switch MAC address groups, which are

selected from the drop-down list:

ALL Select this item to show all of the Moxa switch’s MAC addresses.

ALL Learned Select this item to show all of the Moxa switch’s Learned MAC addresses.

ALL Static Lock Select this item to show all of the Moxa switch’s Static Lock MAC addresses.

ALL Static Select this item to show all of the Moxa switch’s Static, Static Lock, and Static

Multicast MAC addresses.

ALL Static Multicast Select this item to show all of the Moxa switch’s Static Multicast MAC addresses.

Port x Select this item to show all of the MAC addresses dedicated ports.

The table displays the following information:

MAC This field shows the MAC address.

Type This field shows the type of this MAC address.

Port

This field shows the port that this MAC address belongs to.
