PT-7528 Series Advanced Settings

4-57

Type 1

Traffic Rate Limiting Settings

Control Mode Description Factory Default

Normal Set the max. ingress rate limit for different packet types

Normal

Port Disable When the ingress multicast and broadcast packets exceed the

ingress rate limit, the port will be disabled for a certain period.

During this period, all packets from this port will be discarded.

Ingress Rate Limit - Normal

Policy Description Factory Default

Limit All

Select the ingress rate limit for different

packet types from the following options:

Not Limited, 128K, 256K, 512K, 1M, 2M,

4M, 8M

Limit Broadcast 8M

Limit Broadcast, Multicast, Flooded Unicast

Limit Broadcast, Multicast

Limit Broadcast

Ingress Rate Limit – Port Disable

Setting Description Factory Default

Port disable duration (1~65535

seconds)

When the ingress multicast and broadcast packets

exceed the ingress rate limit, the port will be disabled

for this period of time. During this time, all packets

from this port will be discarded.

30 second

Ingress (fps)

Select the ingress rate (fps) limit for all packets from

the following options: Not Limited, 4464, 7441,

14881, 22322, 37203, 52084, 74405

Not Limited
