Moxa Command Line Interface (FW_4.x) Commands
2-120
Usage
Guidelines
2*( hello-time + 1.0 sec) <= max-age <= 2*( forward-delay - 1.0 sec)
Examples
PT-7828(config-rdnt)# spanning-tree mst hello-time 1
<UINT:time> - set mstp hello time
Error
messages
MSTP hello time must be in the range from 1 to 10
MSTP hello time set error
Related
commands
show redundancy mst configuration
spanning-tree mst instance
Use the spanning-tree mst instance redundancy configuration command on the switch to setting the MSTP
instances. Use the no form of this command to remove the setting.
Commands
spanning-tree mst instance instance-id vlan vlan-id-list
no spanning-tree mst instance instance-id vlan vlan-id-list
Syntax
Description
spanning-tree Configure spanning tree
mst Configure mstp
Instance Configure mstp msti
instance-id MSTP instance ID
vlan Configure mstp msti vlan mapping
vlan-id-list Configure mstp msti vlan mapping
Defaults N/A
Command
Modes
Redundancy configuration
Usage
Guidelines
N/A
Examples
PT-7828(config)# spanning-tree mst instance 1 vlan 2
<STRING:instids> - Configure mstp msti
<STRING:vidlist> - Configure mstp msti vlan mapping
Error
messages
The instance id must be in the range from 1 to 16.
vlan 4097 is invalid!! should be range from 1 to 4094
The maximum VLAN mapping is 64.
The vlan id 2 setting is exist in another instance.
MSTI 1 vlan id 2 set error
Related
commands
show redundancy mst instance
spanning-tree mst instance cost
Use the spanning-tree mst instance cost interface configuration command on the switch to set the port cost
of the MSTP instances. Use the no form of this command to return to the default setting.
Commands
spanning-tree mst instance instance-id-list cost cost
no spanning-tree mst instance instance-id-list cost
Syntax
Description
spanning-tree Configure spanning tree
mst Configure mstp
instance Configure mstp msti port
instance-id-list MSTP instance IDs
cost Configure mstp msti port path cost
