interface vlan
Use the interface vlan global configuration command on the switch to create or access a dynamic switch
virtual interface (SVI) and to enter interface configuration mode. Use the no form of this command to delete an
SVI.
Commands
interface vlan vlan-id
no interface vlan vlan-id
Syntax
Description
interface Select an interface to configure
vlan Configure L3 interface
vlan-id Configure L3 interface vlan id
Defaults N/A
Command
Modes
Global configuration
Usage
Guidelines
Management vlan id cannot be same as interface vlan id.
Examples
PT-7828(config)# interface vlan 2
<UINT:vlanid> - Configure L3 interface vlan id
Error
messages
interface vlan 2 is not exist
mgmt vlan id cannot be same as interface vlan id!!
vlan interface full
Related
commands
show interfaces vlan
ip address
Use the ip address VLAN configuration command on the switch to configure the address of a Layer 3 interface.
Commands
ip address ip-address netmask
Syntax
Description
ip Configure L3 interface ip
address Interface ip setting
ip-address IP address
netmask IP netmask
Defaults N/A
Command
Modes
VLAN configuration
Usage
Guidelines
N/A
Examples
PT-7828(config-vlan)# ip address 10.10.10.10 255.255.255.0
ip - Configure L3 interface ip
Error
messages
IP or netmask invalid
vlan 4097 is invalid!! should be range from 1 to 4094
vlan interface full
Interface VLAN is not allowed to modify!!
Related
commands
show interfaces vlan
