DA-682A-DPP Hardware Hardware Installation

2-11

4. Insert the CompactFlash card into the socket.

5. Replace the top cover of the computer and fasten the screws.

ATTENTION

You must disconnect or remove the power source before inserting or removing the CompactFlash card.

The

-682A-DPP rackmount computer does not support CompactFlash hot swap and PnP (Plug and Play)

functions

Installing a Disk on Module (DOM)

The DA-682A-DPP stores its operating system on a disk-on-module (DOM) that is pre-installed on the computer.

You can also install your own DOM as per the following instructions:

1. Disconnect the DA-682A-DPP from its power source.

2. Unfasten the screws on the back of the computer, and then take off the upper cover.

3. Find the location of the DOM socket.

4. Remove the old DOM, and then insert the new DOM into the slot.

5. When finished, replace the upper cover of the computer and fasten the screws.
