TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-6
-- 1.3.6.1.4.1.8691.17.1.4.2
biosSaveSetting OBJECT-TYPE
SYNTAX INTEGER
{
none(0),
apply(1),
discard(2)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Write 1 to save bios setting, and read 0 mean setting had been applied."
::= { biosMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.4.3
biosSettingStatus OBJECT-TYPE
SYNTAX INTEGER
{
same(0),
modified(1)
}
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Showing compare of bios CMOS setting and bios new setting."
::= { biosMgmt 3 }
-- 1.3.6.1.4.1.8691.17.1.4.4
bootSequence OBJECT IDENTIFIER ::= { biosMgmt 4 }
-- 1.3.6.1.4.1.8691.17.1.4.4.1
bootDeviceStatus OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Showing the current support boot device."
::= { bootSequence 1 }
-- 1.3.6.1.4.1.8691.17.1.4.4.2
firstBootDevice OBJECT-TYPE
SYNTAX Integer32 (1..99)
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"read show current first boot device, write set boot device."
::= { bootSequence 2 }
-- 1.3.6.1.4.1.8691.17.1.4.8
powerFeature OBJECT IDENTIFIER ::= { biosMgmt 8 }
-- 1.3.6.1.4.1.8691.17.1.4.8.1
pwrOnAfterPwrFail OBJECT-TYPE
SYNTAX INTEGER
{
