TC-6110 Linux User's Manual Moxa’s Rcore Software Packages
4-4
1. The temperature sensor configuration file is the same as the accelerometer configuration file:
mxsensor.conf. In the screenshot below you see the portion of the configuration file relevant to the
temperature sensor. Edit this to configure how the temperature sensor will be logged.
moxa@Moxa:~# sudo vi /etc/mx_sensor.conf.
2. Save the file and exit your editor (in VI, that is done by typing :wq).
3. Restart Safeguard so that the changes will take effect:
moxa@Moxa:~# sudo /etc/init.d/mx_safeguard restart
4. If the accelerometer log status is set to 1 (enabled), a log file will be recorded at the specified path.
5. Below is a sample accelerometer log.
Removing the Moxa Predictive Maintenance Diagnostic Tool
Use dpkg, apt, or aptitude to remove Safeguard. The dpkg is:
moxa@Moxa:~# dpkg -r moxa-SafeGuard-TC-6110
