TC-6110 Linux User's Manual Managing Communications
3-4
Adjusting IP Addresses with ifconfig
IP settings can be adjusted during run-time, but the new settings will not be saved to the flash ROM without
modifying the file
/etc/network/interfaces. For example, the following command changes the IP
address of LAN1 to 192.168.1.1.
moxa@MOXA:~# sudo ifconfig eth0 192.168.1.1
Point-to-Point Over Ethernet (PPPoE)
Configuration
The Easy Way: pppoeconf
The easiest way to set up a PPPoE connection is to install the Debian package, pppoeconf. This is a script that
automates the PPPoE configuration process; it may be used on any connection that is directly linking to an
ADSL or other PPPoE modem.
Use apt-get or Aptitude to install ppoeconf:
moxa@Moxa: ~# apt-get pppoeconf
After installing pppoeconf, call it from the command line:
moxa@MOXA:~# pppoeconf
Next, a dialog will appear telling you pppoeconf is locating your “access concentrator.” If your DSL or ADSL
modem is connected to an active LAN interface, pppoeconf will find it.
If there are no available concentrators, pppoeconf will tell you, and exit; if this happens, check to see you’re
your modems are connected properly.
If pppoeconf successfully discovers a concentrator on an available interfaces, it will return this screen:
Answer yes. You will then see this screen:
