TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-9
voltSensorsValue
Integer32
}
-- 1.3.6.1.4.1.8691.17.1.5.1.2.1.1
voltSensorsIndex OBJECT-TYPE
SYNTAX Integer32 (1..65535)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Reference index for each observed device."
::= { voltSensorsEntry 1 }
-- 1.3.6.1.4.1.8691.17.1.5.1.2.1.2
voltSensorsDevice OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"The name of the device we are reading."
::= { voltSensorsEntry 2 }
-- 1.3.6.1.4.1.8691.17.1.5.1.2.1.3
voltSensorsValue OBJECT-TYPE
SYNTAX Integer32
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"The voltage in mV."
::= { voltSensorsEntry 3 }
-- 1.3.6.1.4.1.8691.17.1.5.1.3
accelerometerTable OBJECT-TYPE
SYNTAX SEQUENCE OF AccelerometerEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Table of accelerometer and their values."
::= { sensorObject 3 }
-- 1.3.6.1.4.1.8691.17.1.5.1.3.1
accelerometerEntry OBJECT-TYPE
SYNTAX AccelerometerEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"An entry containing a device and its statistics."
INDEX { accelerometerIndex }
::= { accelerometerTable 1 }
AccelerometerEntry ::=
SEQUENCE {
accelerometerIndex
Integer32,
accelerometerAxis
