TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-2
--
-- Type definitions
--
Minutes ::= Integer32
KBytes ::= INTEGER
Second ::= Integer32
--
-- Node definitions
--
-- 1.3.6.1.4.1.8691
moxa OBJECT IDENTIFIER ::= { enterprises 8691 }
-- 1.3.6.1.4.1.8691.17
embeddedComputer OBJECT IDENTIFIER ::= { moxa 17 }
-- 1.3.6.1.4.1.8691.17.1.1
productInfoMgmt OBJECT IDENTIFIER ::= { moxaSystem 1 }
-- 1.3.6.1.4.1.8691.17.1.1.1
productName OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Showing product name, eg. UC7110-LX/IA240-LX/DA683-LX/DA683-XPE."
::= { productInfoMgmt 1 }
-- 1.3.6.1.4.1.8691.17.1.1.2
productDesc OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Showing product short description.(if one exists)."
::= { productInfoMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.1.3
productVersion OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Showing product version eg. 1.0/1.0.1"
::= { productInfoMgmt 3 }
-- 1.3.6.1.4.1.8691.17.1.1.4
productBuildDate OBJECT-TYPE
SYNTAX DisplayString
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Showing product last build date, the format is YYMMDDHH.
