TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-4
Note that this is same as hrMemorySize in HOST-RESOURCE."
::= { systemStorageObject 1 }
-- 1.3.6.1.4.1.8691.17.1.2.3.2
systemVolumeCount OBJECT-TYPE
SYNTAX Integer32
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Show total volume count."
::= { systemStorageObject 2 }
-- 1.3.6.1.4.1.8691.17.1.2.3.3
systemVolumeTable OBJECT-TYPE
SYNTAX SEQUENCE OF SystemVolumeEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Table of File System Volume and their values."
::= { systemStorageObject 3 }
-- 1.3.6.1.4.1.8691.17.1.2.3.3.1
systemVolumeEntry OBJECT-TYPE
SYNTAX SystemVolumeEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"An entry containing a device and its statistics."
INDEX { systemVolumeIndex }
::= { systemVolumeTable 1 }
SystemVolumeEntry ::=
SEQUENCE {
systemVolumeIndex
Integer32,
systemVolumeName
OCTET STRING,
systemVolumeLabel
OCTET STRING,
systemVolumeSize
OCTET STRING,
systemVolumeAvail
OCTET STRING
}
-- 1.3.6.1.4.1.8691.17.1.2.3.3.1.1
systemVolumeIndex OBJECT-TYPE
SYNTAX Integer32
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Reference index for each observed device."
::= { systemVolumeEntry 1 }
-- 1.3.6.1.4.1.8691.17.1.2.3.3.1.2
