Figure 5.13

2) View live PIDs on the screen. Use the UP/DOWN scroll button

for more PIDs if additional information is available on more than

one page.

Figure 5.14

 The number “x” to the right of the screen indicates sequence

of the highlighted item.

 To view full name of the highlighted PID, press the

○

button.

 If the “G” icon appears when a PID is highlighted, graphic

information is available. Press OK to view graph.

…………………View Data 1/3.

Complete Data Set

Custom Data Set

Unit of Measure ?

Live Data 6

DTC_CNT 0

FUELSYS1 0L

FUELSYS2 -- ?

LOAD_PCT (%) 0.0

ETC(℃) -40

SHRTFT1 (%) 99.2
