Getting Started with NETGEAR Genie
18
N300 Wireless Gigabit Router WNR3500Lv2
1. Launch your browser from a computer or wireless device that is connected to the router.
2. Type http://www
.routerlogin.net or http://www.routerlogin.com.
The login window displays:
admin
********
3. Enter admin for the router user name and password for the router password, both in
lowercase letters.
Note: The router user name and password are different from the user name
and pa
ssword for logging in to your Internet connection. See Types of Logins
and Access on page 16
for more information.
Upgrade Router Firmware
When you set up your router and are connected to the Internet, the router automatically
checks for you to see if a newer firmware is available. If it is, a
message is displayed on the top
of the screen
. See Upgrade the Router Firmware on page 62 for more information about
upgrading firmware.
Click the message when it shows up, and click Yes
to upgrade the router with the latest
firmware. After the upgrade, the router restarts.
CAUTION:
Do not try to go online, turn off the router, shut down the computer, or do
anything else to the router until the router finishes restarting and the Power
LED has stopped blinking and has turned to steady green for several
seconds.
