![Netgear WNR3500L [47/114] Usb drive requirements](/views2/1205514/page47/bg2f.png)
USB Storage
47
N300 Wireless Gigabit Router WNR3500Lv2
USB Drive Requirements
The router works with 1.0 and 1.1 (USB Full Speed) and 2.0 (USB High Speed) standards.
The approximate USB bus speeds are shown in the following table. Actual bus speeds can
vary, depending on the CPU speed, memory, speed of the network, and other variables.
Table 3. USB drive speeds
Bus Speed/Sec
USB 1.1 12 Mbits
USB 2.0 480 Mbits
The router should work with most USB-compliant external flash and hard drives. For the most
up-to-date list of USB drives supported by the router, go to:
http://kbserver.netgear.com/readyshare
The router supports both read and write for FAT16, FAT32, NTFS, and Linux file systems
(EXT2 and EXT3).
Note: Some USB external hard drives and flash drives require drivers to
be loaded in to the PC before the PC can access the USB device.
Such USB devices will not work with the router.
ReadySHARE Access
Once you have set up your router, you can connect any USB storage device and share the
contents with other users on your network. When you attach a USB storage device, the
router automatically scans it for files.
You can access your USB device in any of the following ways:
• On Windows 7, Windo
ws XP, Windows Vista, and Windows 2000 systems, select Start >
Run and enter \\readyshare in the dialog box. Click OK.
• On Windows 7, Windo
ws XP, Windows Vista, and Windows 2000 systems, open Internet
Explorer, and enter \\readyshare in the address bar.
• On Mac OS X (version 10.2 or later), enter sm
b://readyshare in the address bar.
• In My Network Places, enter \\rea
dyshare in the address bar.
