Troubleshooting
95
N300 Wireless Gigabit Router WNR3500Lv2
Troubleshooting with the LEDs
After you turn on power to the router, the following sequence of events should occur:
1. When power is first applied, verify that the Power LED
is on.
2. Verify that the Power LED turns amber within a few seconds, indicating that the self-test is
running
.
3. After approximately 30 seconds, verify that:
•
The Power LED
is solid green.
• The Internet LED is on.
•
A numbered Eth
ernet port LED is on for any local port that is connected to a
computer. This indicates that a link has been established to the connected device.
The LEDs on the front panel of the router can be used for troubleshooting.
Power LED Is Off or Blinking
• Make sure that the power cord is securely connected to your router and that the power
adapter is securely connected to a functioning power outlet.
• Check that you
are using the 12V DC, 1.5A power adapter that NETGEAR supplied for
this product.
• If the Power LED blinks slowly and continuously, the
router firmware is corrupted. This
can happen if a firmware upgrade is interrupted, or if the router detects a problem with the
firmware. If the error persists, you have a hardware problem. For recovery instructions, or
help with a hardware problem, contact technical support at www.netgear.com/support.
Power LED Stays Amber
When the router is turned on, the Power LED turns amber for about 20 seconds and then
turns green. If the LED does not turn green, the router has a problem.
If the Power LED is still amber 1 minute after you turn on power to the router:
1. Turn the power off and back on to see if the router recovers.
2. Press and hold the Restore Fa
ctory Settings button to return the router to its factory
setting, as explained in Troubleshoot Your Network Using the Ping Utility on page 10
0.
If the error persists, you might have a hardware problem and should contact technical
support at www
.netgear.com/support.
LEDs Never Turn Off
When the router is turned on, the LEDs turns on for about 10 seconds and then turn off. If all
the LEDs stay on, there is a fault within the router.
If all LEDs are still on 1 minute after power-up:
