Netgear WNR3500L [61/114] Managing your network

7. Administration

Managing your network

This chapter describes the router settings for administering and maintaining your router and

home network. See also Remote Management on p

age 88 for information about upgrading

or checking the status of your router over the Internet, and Traffic Meter on p

age 91 for

information about monitoring the volume of Internet traffic passing through your router’s

Interne

t port.

This chapter includes the following sections:

• Upgrade the Router Firmware

• View Router Status

• View Logs of Web Access or Attempted Web Access

• Manage the Configuration File

• Set Password
