VS0102/04/08 RS-232 Control Tool
10
Switch Port Commands
The actions can also be performed by keying the command into the text box,
and clicking SEND or pressing the [Enter] key, as described below.
The available formulas for Switch Port commands are as follows:
1. Switch Command + Output Command + Port Number + Control
For example, to turn on output port 02, type the following:
sw o02 on
-or-
For example, to turn off output port 01, type the following:
sw o01 off
Possible Values
The following table shows the possible values for the Switch Port commands:
Command Description
sw Switch command.
Output Command Description
o Output command.
Port Number Description
yy 01-08 port (default is 01).
* All output ports.
Control Description
on Turn on the display.
off Turn off the display.
