VS0102/04/08 RS-232 Control Tool
17
Mute Commands:
The actions can also be performed by keying the command into the text box,
and clicking SEND or pressing the [Enter] key, as described below.
1. Mute Command + Output Command + Port Number + Control
For example, to mute the audio for output port 04, type the following:
mute o04 on
-or-
For example, to turn on the audio for output port 04, type the following:
mute o04 off
Possible Values
The following table shows the possible values for the Mute commands:
Command Description
mute Mute command.
Output Command Description
o Output command.
Port Number Description
yy 01-08 port (default is 01).
* All ports.
Control Description
on Mute on; audio of output port is
disabled.
off Mute off; audio of output port is
enabled (default).
