VS0102/04/08 RS-232 Control Tool
15
EDID Mode Commands Table
After commands are sent acknowledge messages are returned.
Note: 1. Each command string can be separated with a space.
2. The Port Number command string can be skipped, and the default
value will be used.
Command Control Enter Description
edid port1 [Enter] The EDID from Port 1 is passed to the
video source for use with all displays.
edid auto [Enter] The VS0102 / VS0104 / VS0108
implements the true EDID remix of all
connected displays and uses the best
resolution for all displays.
edid default [Enter] ATEN’s default EDID is passed to the
video source.
Ack Description
Command OK Command is correct and function executed.
Command Incorrect Unavailable command or parameters.
