VS0102/04/08 RS-232 Control Tool
18
Mute Commands Table
After commands are sent acknowledge messages are returned.
Note: 1. Each command string can be separated with a space.
2. The Port Number command string can be skipped, and the default
value will be used.
Command Output Port Control Enter Description
mute o yy on [Enter] Mute on for output port
yy (no audio).
mute o yy off [Enter] Mute off for output port
yy (audio on).
mute o * on [Enter] Mute on for all ports (no
audio).
mute o * off [Enter] Mute off for all ports
(audio on).
Ack Description
Command OK Command is correct and function executed.
Command Incorrect Unavailable command or parameters.
