VS0102/04/08 RS-232 Control Tool
11
Switch Port Commands Table:
After commands are sent acknowledge messages are returned.
Note: 1. Each command string can be separated with a space.
2. The Port Number command string can be skipped, and the default
value will be used.
Command Input Port Control Enter Description
sw o yy on [Enter] Turn on display port yy.
sw o yy off [Enter] Turn off display port yy.
sw o * on [Enter] Turn on all displays.
sw o * off [Enter] Turn off all displays.
Ack Description
Command OK Command is correct and function executed.
Command Incorrect Unavailable command or parameters.
