VS0102/04/08 RS-232 Control Tool
20
Read Info Commands:
The actions can also be performed by keying the command into the text box,
and clicking SEND or pressing the [Enter] key, as described below.
1. Read Command + Control
For example, to read the firmware version, type the following:
read version
2. Read Command + Output Command + Port Number + Control
For example, to display the video on/off status for port 03, type the following:
read o03 video
Possible Values
The following table shows the possible values for the Read Info commands:
Command Description
read Read info command.
Output Command Description
o Output command.
Port Number Description
yy 01-08 port (default is 01).
* All ports.
Control Description
version Read firmware version.
edid Read EDID information
(For port 01 only).
video Read video on/off status.
audio Read audio on/off status.
