VS0102/04/08 RS-232 Control Tool
3
RS-232 Control Tool Operation
Overview
The VS0102 / VS0104 / VS0108’s built-in bi-directional RS-232 serial
interface allows system control through a high-end controller, PC, and/or home
automation / home theater software package. The RS-232 Control Tool is an
application used to send operational commands from your PC – to the VS0102
/ VS0104 / VS0108 through a serial (RS-232) interface connection. RS-232
serial operations to and from the VS0102 / VS0104 / VS0108 can be managed
using ATEN’s Graphical User Interface (GUI) on computers that are running
the Microsoft Windows operating system. In order to use the RS-232 Control
Tool, two separate programs must be installed on the PC- .NET Framework 2.0
and the RS-232 Control Tool. The procedure for installing and operating the
RS-232 Control Tool is detailed in the following sections.
Before You Begin
Installing .NET Framework 2.0
To install .NET Framework on your PC, do the following:
1. Download the executable file from the ATEN website or the Microsoft
Download Center online, and run it.
2. Follow the instructions on the screen. The installation applet will
automatically detect the operating system and install the correct drivers
Installing the RS-232 Control Tool
To install the RS-232 Control Tool, do the following:
1. Download the RS-232 Control Tool from the Download or VS0102 /
VS0104 / VS0108’s Resource page on our website:
www.aten.com
2. Save the file to a convenient location.
