VS0102/04/08 RS-232 Control Tool
14
EDID Mode Commands:
The actions can also be performed by keying the command into the text box,
and clicking SEND or pressing the [Enter] key, as described below.
1. EDID Command + Control
For example, to change the EDID setting to Auto, type the following:
edid auto
Possible Values
The following table shows the possible values for the EDID commands:
Command Description
edid EDID mode command.
Control Description
port1 Implement the EDID of the
display connected to Port 1, and
pass it to the video source for
use with all displays.
auto Implements the true EDID remix
of all connected displays. The
VS0102 / VS0104 / VS0108
uses the best resolution for all
displays.
default Implements ATEN’s default
EDID.
