VS0102/04/08 RS-232 Control Tool
23
Reset Commands:
The actions can also be performed by keying the command into the text box,
and clicking SEND or pressing the [Enter] key, as described below.
1. Reset Command + Output Command + Port Number
For example, to reset port 02 back to the factory default settings, type the
following:
reset o02
Possible Values
The following table shows the possible values for the Reset commands:
Command Description
reset Resets command.
Output
Command
Description
o Output Command.
Port Number Description
yy 01-08 port (default is 01).
* All ports.
