Introducing the Motherboard
Table of Motherboard Components
7 IDE2 Secondary IDE connector
This concludes Chapter 1. The next chapter explains how to install the motherboard.
15 AUDIO1 Front panel audio header
LABEL COMPONENT
1 CPU Socket Socket 939 for AMD K8 processor
6 IDE1 Primary IDE connector
8 SATA1~SATA2 Serial ATA connectors
10 CLR_CMOS Clear CMOS jumper
5 FDD Floppy disk drive connector
17 PCI1~3 32-bit add-on card slots
12 BIOS_WP BIOS flash protect jumper
2 CPU_FAN CPU cooling fan connector
19 ATX12V 4-pin power connector
3 DIMM1~2 184-pin DDR SDRAM slots
16 CD_IN Analog audio input connector
4 ATX_POWER1 Standard 24-pin ATX power connector
11 F_USB1~2 Front Panel USB headers
20 SYS_FAN System cooling fan connector
18 PCIEX1 PCI Express x16 Slot
9 PANEL Front Panel switch/LED header
14 WOL Wake On LAN connector
13 WOM Wake On Modem connector
