45
Using BIOS
Frequency/Voltage Control
This item enables you to set the clock speed and system bus for your system. The clock
speed and system bus are determined by the kind of processor you have installed in your
system.
Item Help
Menu Level
CPU Frequency [200.0]
Hammer Fid Control [Start up]
CPU Frequency (200.0)
This item indicates the CPU frequency. Users can not make any change to this item. Please
noted that the frequency will be varied with different CPU.
Hammer Fid Control (Start up)
This item allows users to adjust the CPU frequency; the range will be varied according to
different CPUs. We strongly recommend you leave this item at its default value.
Press <Esc> to return to the main menu setting page.
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Phoenix - Award WorkstationBIOS CMOS Setup Utility
Frequency/Voltage Control
