39
Using BIOS
Press <Esc> to return to the Integrated Peripherals page.
Press <Esc> to return to the Integrated Peripherals page.
Enables or disables the Onboard Lan boot rom function.
Init Display First [PCI Slot]
This item allows users to set the initial display device for the system.
Onchip USB (V1.1+V2.0)
This item enables users to enable or disable the onchip USB function, setting it to be
USB1.1 or USB2.0 compatible.
Onboard Lan (Enabled)
Onboard Lan Boot ROM (Disabled)
AC97 Audio (Auto)
Enables or disables the Onboard Lan function.
This item allows you to control the Onboard AC 97 audio. Disable this item if you are going
to install a PCI audio add-on card.
USB Mouse Support (Enabled)
USB Keyboard Support (Enabled)
Enable this item if you plan to use a mouse connected through the USB port in a legacy
operating system (such as DOS) that does not support Plug and Play.
Enable this item if you plan to use a keyboard connected through the USB port in a legacy
operating system (such as DOS) that does not support Plug and Play.
Onboard Device (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
Init Display First [PCI Slot]
OnChip USB [V1.1+V2.0]
USB Keyboard Support [Enabled]
USB Mouse Support [Enabled]
AC97 Audio [Auto]
Onboard Lan [Enabled]
Onboard Lan Boot ROM [Disabled]
Menu Level
Item Help
Phoenix - Award WorkstationBIOS CMOS Setup Utility
Onboard Device
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
SATA 1/2 RAID (Disabled)
These two items enable or disable the SATA1/2 RAID.
RAID Enable (Disabled)
This item allows you to enable or disable the onboard RAID function of RAID supporting
devices.
