Multi-Language Translation
Italiano
I/O integrati
La scheda madre offre una serie completa di porte e connettori I/O:
• Due porte PS/2 per mouse e tastiera
• Una porta seriale
• Una porta parallela
• Quattro porte USB
• Una porta VGA
• Una porta LAN (opzionale)
• Prese jack audio per microfono, line-in e line-out
Firmware BIOS
La scheda madre si avvale del BIOS AWARD che consente la configurazione personalizzata di
molte funzionalità del sistema, tra cui:
• Gestione dell’alimentazione
• Allarmi di attivazione
• Parametri CPU
• Sincronizzazione di CPU e memoria
Il firmware consente inoltre di impostare i parametri per diverse velocità di clock del
processore.
Alcune specifiche hardware e voci di software possono essere modificate senza
preavviso.
La scheda madre supporta bus master UltraDMA con tasso di trasferimento di 133/100/66 MB/
s.
La scheda madre è dotata delle seguenti opzioni di espansione:
• Un slot PCI Express x16
• Tre slot PCI 32 bit a 33 MHz
• Due connettori IDE per il supporto di 4 componenti IDE
• Un’interfaccia per unità disco floppy
• Due connettori SATA a 7 pin
Opzioni di espansione
LAN integrata (opzionale)
La funzionalità LAN integrata sulla scheda offre le seguenti caratteristiche:
• Supporto operazioni di auto negoziazione N-Way a 10/100 Mb/s
• Supporto di funzionalità half/full duplex
• Supporto di funzionalità Wake-on-LAN (WOL) e riattivazione remota
• Transceiver 10/100/1000 integrato
• Supporto di PCI v2.3, a 32 bit, 33/66 MHz
• Supporto completo degli standard IEEE802.3, IEEE802.3u e
IEEE802.3ab
• Supporto di auto-negotiation a 10/100 Mb/s
• Supporto di MII e SNI (Serial Network Interface) a 7 fili
• Supporto di auto rilevazione e crossover
