Using BIOS
Standard CMOS Features Frequency/Voltage Control
BIOS Navigation Keys
The BIOS navigation keys are listed below:
Press DEL to enter SETUP
Press the delete key to access the BIOS Setup Utility.
KEY FUNCTION
Scrolls through the items on a menu
Modifies the selected field’s values
Saves the current configuration and exits setup
Displays a screen that describes all key functions
Loads a minimum configuration for troubleshooting
Exits the current menu
Loads previously saved values to CMOS
ESC
+/-/PU/PD
F10
F1
F5
F6
F7
Loads an optimum set of values for peak performance
Phoenix-Award WorkstationBIOS CMOS Setup Utility
PC Health Status Exit Without Saving
Advanced Chipset Features Load Optimized Defaults
Integrated Peripherals Set Supervisor Password
Power Management Setup Set User Password
Time, Date, Hard Disk Type...
PnP/PCI Configurations Save & Exit Setup
Advanced BIOS Features Load Fail-Safe Defaults
F10: Save & Exit Setup
: Select Item
ESC: Quit F9: Menu in BIOS
