38
Using BIOS
Press <Esc> to return to the Integrated Peripherals page.
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
RAID Config (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
RAID Enable [Disabled]
SATA 1 RAID [Disabled]
SATA 2 RAID [Disabled]
Item Help
Menu Level
Phoenix - Award WorkstationBIOS CMOS Setup Utility
RAID Config
IDE DMA transfer access (Enabled)
This item allows you to enable the transfer access of the IDE DMA then burst onto the
PCI bus and nonburstable transactions do not.
Primary/Seconday Master/Slave UDMA (Auto)
Each IDE channel supports a master device and a slave device. This motherboard supports
UltraDMA technology, which provides faster access to IDE devices.
If you install a device that supports UltraDMA, change the appropriate item on this list
to Auto. You may have to install the UltraDMA driver supplied with this motherboard in
order to use an UltraDMA device.
IDE Prefetch Mode (Enabled)
The onboard IDE drive interface supports IDE prefetching, for faster drive access. If you
install a primary and secondary add-in IDE interface, set this field to Disabled if the
interface does not support prefetching.
IDE HDD Block Mode (Enabled)
Block mode is also called block transfer, multiple commands, or multiple sector read/
write. If your IDE hard drive supports block mode, select Enabled for automatic detection
of the optimal number of block read/write per sector the drive can support.
OnChip IDE Channel 1 (Enabled)
This item allows you to enable or disable the onboard IDEdevices.
Serial-ATA Channel 1 (Enabled)
This item allows you to enable or disable the onboard SATA devices.
