ECS Elitegroup C51G-M2 [17/88] Installing the motherboard
![ECS Elitegroup C51G-M2 [17/88] Installing the motherboard](/views2/1212428/page17/bg11.png)
11
Installing the Motherboard
CPU_FAN/SYS_FAN: Cooling FAN Power Connectors
ATX_POWER1: ATX 24-pin Power Connector
ATX12V: ATX 12V Power Connector
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
10 +12V 22 +5V
3 GND 15 GND
4 +5V 16 PS_ON
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 PWRGD 20 -5V
9 +5VSB 21 +5V
Pin Signal Name Pin Signal Name
11 +12V 23 +5V
12 +3.3V 24 GND
Pin Signal Name Function
1 GND System Ground
2 +12V Power +12V
3 Sense Sensor
Pin Signal Name
4 +12V
3 +12V
2 Ground
1 Ground
