Multi-Language Translation
日本語
統合の入出力ポート
マザーボードには、次のI/Oポートやコネクタを揃えています。
• マウスとキーボード用のPS/2ポート x2
• シリアルポート x1
• パラレルポート x1
• USBポート x4
• VGAポート x1
• LANポート x1(オプション)
• マイク、ラインイン、ラインアウト用オーディオジャック
BIOSファームウェア
本マザーボードはAWARD BIOSを採用し、次の機能を含む多様なシステムの構成をを
サポートします。
• 電源管理
• ウェークアップアラーム
• CPUパラメータ
• CPUとメモリとのタイミング
さらに、所定のパラメータを設定することによって、プロセッサのクロック速度を変更す
ることもできます。
一部のハードウェア仕様とソフトウェアアイテムは、予告なしに変更すること
があります。
拡張オプション
本マザーボードでは、次の拡張機能が利用できます。
• PCI Express x16 スロット x1
• 32ビットの33 MHzのPCI スロット x3
• IDEヘッダー x2 (4つのIDEデバイスの接続を可能)
• フロッピーディスクドライブインターフェイス x1
• 7ピンSATAコネクタ x2
このマザーボードは、133/100/66 MB/秒の転送速度でのUltra DMAバスマスタリング
をサポートします。
オンボードLAN (オプション)
オンボードLANは、次の機能を提供します。
• 10/100 Mbps N-way自動ネゴシエーション操作をサポート
• 半/全二重の機能をサポート
• Wake-on-LAN(WOL)と遠隔 wake-upとの機能をサポート
• 10/100/1000 トランシーバーを搭載済み
• PCI v2.3, 32-bit, 33/66-MHzへの対応
• IEEE 802.3、IEEE 802.3u、IEEE 802.3abへの全面対応
• 10/100 Mbps 自動ネゴシエーション操作をサポート
• MII/7-wire SNI (Serial Network Interface)インターフェースをサポート
• 自動クロスオーバー検出機能を搭載
