Multi-Language Translation
Português
I/O Integrado
A motherboard possui um conjunto completo de portas I/O e conectores:
• Duas portas PS/2 para rato e teclado
• Uma porta de série
• Uma porta paralela
• Quatro portas USB
• Uma porta VGA
• Uma porta LAN (opcional)
• Fichas áudio para microfone, entrada de linha e saída de linha
Microprogramação BIOS
Esta motherboard usa AWARD BIOS que permitem aos utilizadores configurar muitas
características do sistema incluindo as seguintes:
• Gestão de corrente
• Alarmes de despertar
• Parâmetros CPU
• Temporização de memória e CPU
A microprogramação poderá ser também usada para estabelecer parâmetros para diferentes
velocidades de relógio do processador.
Algumas especificações de hardware e itens de software poderão ser sujeitos a
alteraçõessem aviso prévio.
A motherboard suporta um domínio bus UltraDMA bus com taxas de Transferência de
133/100/66 MB/s.
A motherboard é fornecida com as seguintes opções de expansão:
• Um ranhura PCI Express x16
• Três ranhuras PCI 32-bit a 33 MHz
• Dois colectores IDE que suportam quatro dispositivos IDE
• Um interface com drive de disco flexível
• Dois conectores SATA de 7 pin
Opções de Expansão
Onboard LAN (opcional)
• Suporta operação de autonegociação N-way de 10/100 Mb/s
•
Suporta capacidade de duplex pela metade/ou na totalidade
• Suporte Wake-on-LAN (WOL) e wake-up remoto
• Transmissor 10/100/1000 integrado
• Suporta PCI v2.3, de 32 bits, 33/66MHz
• Suporta na totalidade IEEE802.3, IEEE802.3u e IEEE802.3ab
• Suporta auto-negociação 10/100 Mb/s
• Suporta MII e 7-wire SNI Interface de Rede de Série (Serial Network Inter-
face)
• Suporta Auto Detecção Crossover
O onboard LAN fornece as seguintes características:
