![ECS Elitegroup C51G-M2 [38/88] Using bios](/views2/1212428/page38/bg26.png)
32
Using BIOS
Advanced BIOS Features
This option defines advanced information about your system.
Menu Level
Item Help
CPU Internal Cache [Enabled]
External Cache [Enabled]
Quick Power On Self Test [Enabled]
First Boot Device [[Floppy]
Second Boot Device [Hard Disk]
Third Boot Device [CDROM]
Boot Other Device [Enabled]
Swap Floppy Device [Disabled]
Boot Up Floppy Seek [Disabled]
Boot Up NumLock Status [On]
Gate A20 Option [Fast]
ATA 66/100 IDE Cable Msg. [Enabled]
Typematic Rate Setting [Disabled]
Typematic Rate (Chars/Sec) 6
Typematic Delay (Msec) 250
Security Option [Setup]
APIC Mode [Enabled]
OS Select For DRAM > 64 MB [Non-OS2]
Hard Disk Boot Priority [Press Enter]
x
x
Select Hard Disk Boot
Device Priority
Hard Disk Boot Priority (Press Enter)
Scroll to this item and press <Enter> to view the following screen: Use this table to decide
the disk boot priority.
1. Pri. Master :
2. Pri. Slave :
3. Sec. Master :
4. Sec. Slave :
5. USBHDD0 :
6. USBHDD1 :
7. USBHDD2 :
8. Bootable Add-in Cards
Menu Level
Use < > or < > to select a
device, then press <+> to
move it up, or <-> to move it
down the list. Press <ESC>
to exit this menu.
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Item Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Press <Esc> to return to the Advanced BIOS Features page.
Phoenix - Award WorkstationBIOS CMOS Setup Utility
Advanced BIOS Features
Phoenix - Award WorkstationBIOS CMOS Setup Utility
Hard Disk Boot Priority
