3-3
3.3 The Main Menu
The main menu of the Setup Utility displays a list of the options that are
available. A highlight indicates which option is currently selected. Use the
cursor arrow keys to move the highlight to other options. When an option
is highlighted, execute the option by pressing <Enter>.
3.3-1 Standard CMOS Features
This option displays basic information about your system.
Phoenix-AwardBIOS CMOS Setup Utility
Standard CMOS Features
Date and Time
The Date and Time items show the current date and time on the
computer. If you are running a Windows OS, these items are automatically
updated whenever you make changes to the Windows Date and Time
Properties utility.
Your computer has two IDE channels (Primary and Secondary) and each
channel can be installed with one or two devices (Master and Slave). Use
these items to configure each device on the IDE channel.
Press <Enter> to display the IDE submenu:
IDE HDD Auto-Detection [Press Enter]
IDE Channel 0 Master [Auto]
Access Mode [Auto]
Capacity 0MB
Cylinder 0
Head 0
Precomp 0
Landing Zone 0
Sector 0
Item Help
Menu Level
To auto-detect the
HDD’s size, head... on
this channel
Phoenix-AwardBIOS CMOS Setup Utility
IDE Channel 0 Slave
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Date (mm:dd:yy) Wed, Jan 25 2005
Time (hh:mm:ss) 9 : 33 : 26
IDE Channel 0 Master [None]
IDE Channel 0 Slave [None]
IDE Channel 1 Master [None]
IDE Channel 1 Slave [None]
IDE Channel 2 Master [None]
IDE Channel 2 Slave [None]
IDE Channel 3 Master [None]
IDE Channel 3 Slave [None]
Drive A [1.44M, 3.5 in.]
Drive B [None]
Floppy 3 Mode Support [Disabled]
Video [EGA/VGA]
Halt On [All Errors]
Item Help
Menu Level
Change the day, month,
year and century
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
IDE Devices (None)
