1.3 Feature Summary
CPU
Chipset
• Northbridge: ATI RD480
• Southbridge: ATI SB450
IEEE 1394a
• VIA IEEE1394a controller
• Supports 2 x IEEE1394a cable ports at 100M bits/s,
200M bits/s, and 400M bits/s
Audio
• Realtek 8-channel audio CODEC
• Compliant with High Definition Audio Codec
• Socket 939 for AMD Athlon 64/Athlon 64 FX CPU
• High-performance HyperTransport CPU Interface
• Transfer rate of 2000/1600/1200/800/400 MT/s
• Dual-channel DDR memory architecture
• 4 x 184-pin, 2.5V, DDR SDRAM DIMM sockets support
up to 4 GB
• Support DDR400/333/266/200 unbuffered DDR
SDRAM
Expansion
Slots
• 2 x PCI Express x16 slots
• 2 x PCI Express x1 slot
• 2 x PCI slots
• Supported by SB450
- 4 x Ultra DMA133/100/66 IDE devices
- 4 x SATA devices
- RAID 0 & RAID 1 configuration
• Supported by SiI3132
- Serial ATA Generation 2 transfer rate of 3.0 Gb/s
- 2 x SATA II devices
- RAID 0 & RAID 1 configuration
Storage
Dual LAN
• Realtek 10/100 Mbps LAN controller
• Marvell Giga LAN controller
Rear panel
I/O
• 1 x PS/2 keyboard connector
• 1 x PS/2 mouse connector
• 4 x USB ports
• 2 x RJ45 LAN connectors
• 1 x Serial port
• 1 x Audio jack (microphone, line-in, and 8-channel line
out)
BIOS features
• Award BIOS with 4Mb or 8Mb Flash ROM
• Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Supports ACPI revision 1.0B specificaion
Internal I/O
• 1 x 24-pin ATX Power Supply Connector & 4-pin 12 V
Connector
• 1 x 4-pin ATX4P1 power connector
