1-1
1.1 Introduction
Thank you for choosing the KA1 MVP motherboard.
The KA1 MVP is the next generation of high performance motherboard
designed to support the AMD Athlon 64/Athlon 64 FX processor. This
motherboard has an ATX form factor that uses a 4-layer printed circuit
board and measures 305 mm x 244 mm.
The KA1 MVP motherboard is based on the ATI RD480 Northbridge and
SB450 Southbridge chipsets to set a new benchmark for the best desktop
platform solution. This motherboard supports up to 4 GB of system memory
with PC3200/2700/2100/1600 DDR DIMMs, high resolution graphics
via two PCI Express slots, Dual LAN, USB 2.0, IEEE 1394, 8-channel
audio, and SATA II (Gen 1 and Gen 2) support with RAID function.
This motherboard complies to ATI’s unique CrossFire
TM
technology, a parallel
processing technology propelling your PC to a new pinnacle of performance
with the ultimate multi-GPU consumer graphics solution. Supporting a
wide range of ATI-based graphics cards and motherboards, the CrossFire
platform offers flexibity and compatibility with all of today’s Radeon X800
®
or Radeon X850
®
graphics cards.
1.2 Package Check List
Motherboard User’s Guide Installation CD
HDD, CD-ROM, and
FDD Cables
USB+1394 PCI
Bracket & housing
Top Hat Flash I/O ShieldSATA Power Cable
SATA Cable Cross Over Cable
All pictures are for reference only.
Shunt Card
eSATA Cable
SPDIF out bracket
