ECS Elitegroup KA1 MVP [71/85] 外形

简体中文

• 1 个 24 针 ATX 电源接口和 1 个 4 针 12 V 接口

• 1 个 4 针 ATX4P1 电源接口

• 1 个软驱接口- 支持 360K ~ 2.88M 字节，3 Mode

FDD 或 LS120

• 2 个 IDE 接口

• 6 个串行 ATA 接口

• 2 个 USB 2.0 接头，支持另外 4 个 USB 端口

• 2 个 1394a 接头

• 1 个 LPT1 接头

• 1 个前面板开关/LED 接头

• 1 个前面板音频接头

• 1 个红外接口

• 1 个 SPK1接口

• 1 个 CD-in接口

• 1 个 SPDIF 输出接口

• CPU_FAN/NB_FAN/SYS_FAN1~3 接口

• ATX 尺寸

• 305mm x 244mm

外形

集成 I/O
