ECS Elitegroup KA1 MVP [77/85] Česky

Česky

• 1x 24kolíkový napájecí konektor ATX a 4kolíkový konektor 12 V

• 1x 4kolíkový napájecí konektor ATX4P1

• 1x konektor ﬂoppy diskových mechanik – podpora 360 kB až 2,88

MB, 3 režimy FDD nebo LS120

• 2x konektor IDE

• 6x konektor Serial ATA

• 2x rozhraní USB 2.0 s podporou dalších 4 USB portů

• 2x rozhraní 1394a

• 1x rozhraní LPT1

• 1x rozhraní pro spínač na předním panelu/LED

• 1x rozhraní pro zvukový vstup/výstup na předním panelu

• 1x infračervené rozhraní

• 1x rozhraní SPK1

• 1x vstup CD

• 1x rozhraní

výstup SPDIF

• Konektory CPU_FAN/NB_FAN/SYS_FAN1~3

• Rozměry standardu ATX

• 305mm x 244mm

Velikost

Interní

vstupy/

výstupy
