ECS Elitegroup KA1 MVP [83/85] Alaki jellemzők

Magyar

• Egy 24 tűs ATX tápforrás csatlakozó és négytűs 12 V-os

csatlakozó

• 1 x 4-pin ATX4P1 elektromos csatlakozó

• Egy ﬂoppy meghajtó 360 kB–2,88 MB lemezeknek, 3

üzemmódú FDD meghajtók vagy LS120

• Két IDE foglalat

• Hat soros ATA csatlakozó

• Két USB 2.0 csatlakozó, és további 4 USB porttal tud

működni

• Két 1394a csatlakozó

• Egy LPT1 csatlakozó

• Egy elülső panelen levő kapcsoló/LED csatlakozó

• Az elülső panelen levő audio csatlakozó

• 1 x Infravörös header

• 1 x SPK1 header

• 1 x CD-in header

• 1 x SPDIF-out header

• CPU_FAN/NB_FAN/SYS_FAN1~3 csatlakozók

• ATX méret

• 305mm x 244mm

Alaki

jellemzők

Belső I/O
