Русский
Характеристики
CPU
Чипсет
• Северный мост: ATI RD480
• Южный мост: ATI SB450
Память
Возможности
расширения
• 2 слотa PCI Express x16
• 2 слотa PCI Express x1
• 2 слота PCI
Массовая
память
• Поддерживаемая SB450
- 4
устройства IDE Ultra DMA133/100/66
- 4 устройства SATA
- Конфигураци RAID 0 & RAID 1
• Поддерживаемая SiI3132
- Serial ATA 2-го поколения со скоростью трансфера 3.0
Гб/с
- 2 устройства SATA II
-
Конфигураци RAID 0, RAID 1, RAID 0+1
IEEE 1394a
• Контроллер VIA IEEE1394a
• Поддержка двух портов IEEE1394a (100M бит/с,
200M бит/с и 400M бит/с)
Aудиo
• 8-канальный аудио CODEC Realtek
• Совместимость с High Definition Audio Codec
Dual LAN
• Контроллер Realtek 10/100 Mbps LAN
•
Контроллер Marvel Gigabit LAN
Гнезда
входа/
выхода на
тыльной
панели
• 1 гнездо клавиатуры PS/2
• 1 гнездо мыши PS/2
• 4 порта USB
• 2 гнезда RJ45 LAN
• 1 серийный порт
• 1 разъем аудио (микрофона, порты входа и 8-канальный
выхода )
• Разъем 939 для процессоров AMD Athlon 64/Athlon 64 FX CPU
• Интерфейс HyperTransport CPU с высокой пропускной
способностью
• Скорость передачи данных 2000/1600/1200/800/400 MT/сек
• Архитектура памяти Dual-channel DDR
• Четыре 184-штырьковых сокета 2.5V DDR DIMM с поддержкой
до 4 ГБ памяти
• Поддержка DDR400/333/266/200 и небуферизуемой памяти
DDR SDRAM
Особенности
BIOS'а
• Award BIOS с 4Mб иди 8Mб Flash ROM
• Поддержка Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Поддержка ACPI вер.1.0B
