3-12
Onboard LAN Boot ROM (Disabled)
Use this item to enable and disable the booting from the onboard LAN or a network add-
in card with a remote boot ROM installed.
Onboard SATA Controller (Both)
This item allows you to manually specify the onboard Serial ATA controller.
Onboard SATA Type (IDE Mode)
This item allows you to manually specify the onboard Serial ATA Type.
USB 2.0 Supports (Enabled)
Enable this item if your system supports USB 2.0.
USB Controller (Enabled)
This item enables or disables the USB controller. Leave this at the default “Enabled” if
you want to connect USB devices to your computer.
USB Legacy Support (Enabled)
Use this item to enable or disable support for legacy USB devices. Setting to Auto
allows the system to detect the presence of USB devices at startup. If detected,
theUSB controller legacy mode is enabled. If no USB device is detected, the legacy
USB support is disabled.
USB Mouse Support (Enabled)
Enable this item if you plan to use a mouse connected through the USB port in a
legacy operating system (such as DOS) that does not support Plug and Play.
SATA2 Controller (Enabled)
This item allows you to enable or disable the SATA2 Controller function.
South OnChip PCI Device (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
Onboard Azalia Audio [Auto]
Onboard 1394 [Enabled]
Onboard PCI LAN [Enabled]
Onboard Lan Boot ROM [Disabled]
Onboard SATA Controller [Both]
Onborad SATA Type [IDE Mode]
USB 2.0 Supports [Enabled]
USB Controller [Enabled]
USB Legacy Support [Enabled]
USB Mouse Support [Enabled]
SATA2 Controller [Enabled]
Giga Lan Controller [Enabled]
Giga Lan Boot Rom [Disabled]
Item Help
Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
SIS OnChip PCI Device
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
x
x
Onboard Azalia AUDIO (Auto)
This option allows you to control the onboard Azalia audio. Disable this item if you are
going to install a PCI audio add-on card.
Onboard 1394 (Enabled)
This option allows you to enable or disable the onboard 1394 function.
Onboard PCI LAN (Enabled)
This option allows you to control the onboard LAN device.
