Français
Résumé des caractéristiques
CPU
Chipset
• North Bridge: ATI RD480
• South Bridge: ATI SB450
Mémoire
Options
d’extension
• 2 x logements PCI Express x16
• 2 x logements PCI Express x1
• 2 x logements PCI
Stockage
• Pris en charge par SB450
- 4 x périphériques IDE Ultra DMA 133/100/66
- 4 x périphériques SATA
- Configuration RAID 0 & RAID 1
• Pris en charge par SiI3132
- Vitesse de transfert ATA Série Génération 2 de 3,0Gb/s
- 2 x périphériques SATA II
- Configuration RAID 0, RAID 1
IEEE 1394a
• Contrôleur IEEE1394a VIA
• Prend en charge 2 ports de câble x IEEE1394a à 100M bits/s,
200M bits/s, et 400M bits/s
Audio
• CODEC audio Realtek 8 canaux
• Conforme aux High Definition Audio Codec
LAN Double
• Contrôleur LAN Realtek 10/100 Mbps
• Marvell Giga LAN
E/S du
panneau
arrière
• 1 x clavier PS/2
• 1 x connecteur souris PS/2
• 4 x ports USB
• 2 x connecteurs LAN RJ45
• 1 x port Série
• 1 x prise Audio (Entrée Micro, sortie de ligne, 8 canaux
d’entrée de ligne )
• Socket 939 pour processeur AMD Athlon 64/Athlon 64 FX
• Interface de CPU HyperTransport de Hautes Performances:
• Vitesse de transfert de 2000/1600/1200/800/400 MT/s
• Architecture mémoire DDR double canal
• 4 x sockets DIMM SDRAM DDR, 2.5V, 184 broches
prenant en charge jusqu’à 4 Go
• Prend en charge les SDRAM DDR sans mémoire tampon
DDR400/333/266/200
Caractéristi-
ques du BIOS
• Award BIOS avec ROM Flash de 4Mb or 8Mb
• Prend en charge Plug & Play 1.0A, APM 1.2, Multi Boot, DMI
• Prend en charge les spécifications 1.0B révision ACPI
