3-16
RTC Alarm Resume (Disabled)
When set to Enabled, the following additional fields become available and you can set
the date (day of the month), hour, minute and second to turn on your system. When
set to 0 (zero) for the day of the month, the alarm will power on your system every day
at the specified time.
• Date of Month: Use this item to define the date of month when using
the RTC alarm to resume the system.
• Resume Time: Use this item to define the time when using the RTC
alarm to resume the system.
Press <Esc> to return to the Power Management Setup screen.
Resume by Ring (Disabled)
This item specifies whether the system will be awakened from power saving modes
when activity or input signal of WOL/WOM/Ring device is detected.
Resume by PCI PME (Enabled)
This item specifies whether the system will be awakened from power saving modes
when activity or input signal of the specified hardware peripheral or component is
detected.
Resume by PCI-E (Enabled)
This item specifies whether the system will be awakened from power saving modes
when activity or input signal of the specified hardware peripheral or component is
detected.
Resume by USB (S3) (Disabled)
This option allows the activity of the USB devices to wake up the system from S3
sleep state.
Resume by PS/2 Mouse (Disabled)
This option allows the activity of the mouse device to wake up the system from
sleeping status.
Resume by PS/2 Keyboard (Disabled)
This option allows the activity of the keyboard device to wake up the system from
sleeping status.
Hot Key Resume (Ctrl-F1)
Use this item to define the password when using the keyboard “hot key” to resume the
system.
