3-9
LDT & PCI Bus Control (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
LDT Configuration [Enabled]
Upstream LDT Bus Width [16 bit]
Downstream LDT Bus Width [16 bit]
LDT Bus Frequency [Auto]
PCIE Reset Delay [Disabled]
Item Help
Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
Advanced Chipset Features
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
LDT Configuration (Enabled)
This item enables or disables the LDT configuration.
Upstream LDT Bus Width (16 bit)
This item allows users to manually adjust the upstream LDT bus width to be 8 bit or 16
bit.
Downstream LDT Bus Width (16 bit)
This item allows users to manually adjust the downstream LDT bus width to be 8 bit or
16 bit.
Press <Esc> to return to the Advanced Chipset Features page.
LDT Bus Frequency (Auto)
This item allows users to manually adjust the LDT Bus Frequency.
PCIE Reset Delay (Disabled)
This item enables or disables the PCIE reset delay.
PCIE GFX Core Payload Size (64 Bytes)
This item allows users to manually adjust the PCIE GFX Core Payload Size.
PCIE GPP Core Payload Size (64 Bytes)
This item allows users to manually adjust the PCIE GPP Core Payload Size.
Dual Slot Configuration (Disabled)
This item allows users to enable or disable the Dual Slot Confuguration.
GFX0/1 Link Width [x16] (x8)
This item allows users to manually set the GFX Link Width.
GFX Multi Function Mode (Disabled)
This item allows users to enable or disable the GFX Multi Function Mode.
AGP Aperture Size (128MB)
This item allows users to manually adjust the AGP aperture size, from 32MB to 2GB.
GFX Clock Mode (Sync])
This item allows users to set the GFX Clock Mode to be Sync or Async. When this item
is set to Sync, the following 3 item is activated.
