26 |SH A WWW.STIEBEL-ELTRON.COM
INSTALLATION
SPECIFICATION
16.4 Hydraulic schematic diagram
KV 30 and TA 260
26_02_10_0219
12
1
1 KV 30
2 TA 260
It is also possible to use thermostat valve TA 260 in combination
with KV 40.
KV 40
1
1
1
1
1
1
1
1
1
1
1
1
26_02_10_0220
1 KV 40
16.5 Specification
Model Closed flue wall mounted DHW cylinder
Type SH 50 A SH 80 A SH 100 A SH 120 A SH 150 A SH 100 A SH 120 A SH 150 A
Part number 073120 073121 073122 073123 073124 073277 073194 073195
Operating details
Rated output kW 2.0 2.0 2.0 3.0 3.0 1.3 2.6 3.9 1.3 2.6 3.9 1.3 2.6 3.9
Power connection
V
1/N/PE
~ 230
1/N/PE
~ 230
1/N/PE
~ 230
1/N/PE
~ 230
1/N/PE
~ 230
1/N/PE
~ 230
1/N/PE
~ 230
3/PE
~ 400
1/N/PE
~ 230
1/N/PE
~ 230
3/PE
~ 400
1/N/PE
~ 230
1/N/PE
~ 230
3/PE
~ 400
Capacity l 50 80 100 120 150 100 100 100 120 120 120 150 150 150
Temperature
range
minimum approx.
maximum approx.
°C
°C
35
82
35
82
35
82
35
82
35
82
35
82
35
82
35
82
35
82
35
82
35
82
35
82
35
82
35
82
Permissible
operating pressure
MPa 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
Water connection
(male thread)
G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2" G 1/2"
Protection level
to EN 60529
IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D IP 25 D
Maximum
flow rate
l/min 18 18 18 18 18 18 18 18 18 18 18 18 18 18
Height mm 740 975 975 1 100 1 280 975 975 975 1 100 1 100 1 100 1 280 1 280 1 280
Width mm 510 510 510 510 510 510 510 510 510 510 510 510 510 510
Depth mm 510 510 510 510 510 510 510 510 510 510 510 510 510 510
Weight, empty kg 27.3 36.1 37.1 40.8 47.4 38.3 38.3 38.3 47.7 47.7 47.7 48.3 48.3 48.3
