(continued on the next page)
ROG STRIX Z370-I GAMING specications summary
Wireless &
Bluetooth
Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz with
MU-MIMO support
Bluetooth v4.2
Audio
ROG SupremeFX S1220A 8-Channel High Denition Audio CODEC
- Supports up to 32-Bit/192kHz playback
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113 dB SNR
recording input
- SupremeFX Shielding Technology
- Dual Headphone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features:
- Sonic Radar III
- Sonic Studio III + Sonic Studio Link
USB
Intel
®
Z370 Chipset:
- 6 x USB 3.1 Gen1 ports ( 3 x Type-A and 1 x Type-C ports at back panel,
2 ports at mid-board)
- 6 x USB 2.0 ports ( 4 ports at back panel, 2 ports at mid-board)
ASMedia
®
USB 3.1 Gen2 controller*:
- 1 x USB 3.1 Gen2 front panel connector
* Supports 3A power output
Back I/O Ports
1 x DispalyPort
1 x HDMI port
1 x Anti-surge LAN (RJ45) port
4 x USB 3.1 Gen1 ports (3 x Type-A [blue] and 1 x Type-C ports at back
panel)
4 x USB 2.0 ports
1 x Optical S/PDIF out
5 x Audio jacks
1 x ASUS Wi-Fi module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.2)
ROG Exclusive
Features
ROG RAMCache II
ROG GameFirst IV
ROG Overwolf
ROG CloneDrive
ASUS Special
Features
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates
better CPU performance, power saving, digital power control, system
cooling and app usages.
DIGI+VRM
TPU
- Auto Tuning, TPU, GPU Boost
EPU
